VEGATOR 141

Single-channel controller for level detection

Transmission of 4 ... 20 mA signals for level signalling (single channel)


VEGATOR 141
VEGATOR 141

Application area

The VEGATOR 141 is a controller for level detection for continuously measuring 4 … 20 mA sensors. It evaluates the measured values of a sensor and delivers a relay switching signal according to the adjusted switching threshold. Hence simple control tasks can be solved. Typical applications are monitoring functions such as overflow and dry run protection as well as gauge monitoring. Optionally a false signal output is available.

Your benefit

  • Simple adjustment of the switching point with potentiometer
  • Simple installation though carrier rail mounting as well as detachable, coded terminals
  • Visible status indication via LED

Base price

¥ 2,901.84

Detailed information on prices and delivery times can be found in the Configurator.

Configure product

All documents and software for this product can be found in our Download Center.

Show all downloads
Application
Technical specifications
Documentation
Accessories
Configure product

Other applications

Sludge dewatering

Sludge dewatering

Level detection of sludge and water

To the application

Sludge granulate silo

Sludge granulate silo

Level measurement and point level detection in the sludge granulate silo

To the application

Lime silo

Lime silo

Level measurement and high level detection in the lime silo

To the application

Digester

Digester

Level measurement and point level detection of foam in the digester

To the application
Technical specifications
Protection rating
  • IP20
Input
  • 1 x 4 … 20 mA sensor input
Output
  • 1 x operating relay (SPDT)
  • Optionally 1 x fail safe relay output (SPDT)
Ambient temperature
  • -20 ... 60 °C
Signal input (specify)
  • 4 … 20 mA
Signal output (specify)
  • Operating relay
  • Fail safe relay
Approvals
Scope
  • ATEX / Europe
  • IEC / worldwide
  • NEPSI / China
  • INMETRO / Brazil
Ship approval
  • ABS
  • BV
  • CCS
  • GL
  • LR
  • RINA
SIL qualification
  • SIL2
Display & adjustment
Adjustment
  • DIP switch
Indication
  • LED
