Vacuum evaporator with scraper system

Level measurement in a vacuum evaporator with scraper system and pressure monitoring in the supply line

Process data

Measuring task:
Level and pressure measurement
Measuring point:
Measuring range up to:
1.6 m
Extracted solution
Process temperature:
+50 ... +80 °C
Process pressure:
-0.7 ... -0.5 bar
Special challenges:
Vacuum, buildup, condensation, vessel internals


A thickening vessel fitted with a scraper is used to increase the concentration of extracted solutions by means of evaporation under vacuum. Extremely precise level measurement is required in this process because the concentration is determined by the filling height. The evaporation system operates according to meeting specified levels. As soon as they reach the correct value, the evaporation process is stopped and the concentrated solution is discharged out of the tank.

Your benefit

Optimal concentration thanks to highly accurate level measurement
Cost effective
Easy cleaning without dismantling
User friendly
Simple installation and setup
